| Model | YLB-18S |
| Materials | All kinds of powder materials |
| Range（ml） | 1-50ml |
| Sachet size（mm） | W:30-100 L:30-150 |
| Max. film width（mm） | 220 |
| Sachet type | Three sides seal / four sides seal |
| Fill method | Auger screw |
| Control | PLC |
| Capacity(sachet/min) | 20-35 |
| Dimension（L*W*H）(mm) | 900*700*1700 |
| Weight(kg) | 200 |
| Power/Voltage | 220V/50-60HZ/1.0KW |
| Case and all contacting parts | 304SUS |
| Functions | Automatic feeding, forming, filling, sealing, coding, cutting, etc. |
| Packaging Materials | All kinds of laminated films |
| Advantages |
. Pneumatic control for filling and sealing, easy for operation and maintenance . . With high quality compnents: Omron PLC, Omron Touch Screen, Omron Temperature Control, Omron Solid Relay, Schneider power control, Schneider Servo Motor, AirTac Cylinders, etc. . . With Servo motor bag pulling, more steady and accurate than step motor. . . Whole machine with 6.0mm 304SUS frame, covered with 1.5-2.0mm 304SUS sheets. . . With accurate eyemark sensor to control bag length and auto-stop if lack of film or any mistake occurred. . . With intellegent temperature controller to control each sealer accurately and evenly. . . With auto feeding system to save hands. . |
