Features
◆Compact Design
◆Driving Parts Fully-closed
◆Pneumatic Tube Washing & Feeding
◆Intelligent Temperature Control and Cooling System
◆Easy to Operate and Adjust
◆316L Stainless Steel Contact Parts to meet GMP Standard
◆Safety Interlock Shutdown when Door is Open
◆Overload Protection Provided
◆Automated Working process from Tube Loading to Finished Products Output
◆Automatic Orientation Effected by Photoelectric Induction
Optional Devices
◆Chiller
◆Date Coding Embossing
◆Automatic Tube Feeding Magazine
◆Change Parts
Technical Parameters
Filling volume:1-120ml/unit (Adjustable)
Filling accuracy: ≦±1﹪
Capacity: 2400-3600units/hour (Adjustable)
Tube diameter: Φ10-28 mm
Tube length: 50-180mm
Hopper volume: 40L
Equipped motor: 1.1KW:
Machine power: 2kw
Dimension: 1950×750×1850(mm)
Power supply: 380/220 (Optional)
Weight: About 900 Kg
