Features
◆Compact Design
◆Driving Parts Fully-closed
◆Pneumatic Tube Washing & Feeding
◆Intelligent Temperature Control and Cooling System
◆Easy to Operate and Adjust
◆316L Stainless Steel Contact Parts to meet GMP Standard
◆Safety Interlock Shutdown when Door is Open
◆Overload Protection Provided
◆Automated Working process from Tube Loading to Finished Products Output
◆Automatic Orientation Effected by Photoelectric Induction
Optional Devices
◆Chiller
◆Date Coding Embossing
◆Automatic Tube Feeding Magazine
◆Change Parts
Technical Parameters
Filling volume：1-300ml/unit (Adjustable)
Filling accuracy：≦±0.5﹪
Capacity：3000-4800units/hour (Adjustable)
Tube diameter：Φ10-50 mm
Tube length：210mm (can order)
Hopper volume：40L
Equipped motor：1.1KW
Machine power：2kw
Dimension：22700×960×2100（mm）
Power supply：380/220 (Optional)
Weight：About1200 Kg
